Major League GitHub

Major League GitHub is an open-source, sports-themed leaderboard that ranks GitHub contributors like professional soccer players. It maps open-source developers across the United States by programming language, geographic location, and proximity to MLS stadiums — combining GitHub GraphQL analytics with geospatial modeling to create a gamified developer leaderboard.

Live: https://www.mlg.soccer · Repository: https://github.com/flamingo-stack/major-league-github

---

Features

• Language Filtering — Filter contributors by any programming language (Java, Python, TypeScript, Go, and more)
• Geographic Filtering — Narrow results by city, state, or geographic region
• MLS Stadium Proximity — Rank contributors by distance to the nearest MLS stadium using Haversine distance
• Contributor Scoring — Transparent scoring formula: commits × max(starsReceived, 1) × recencyMultiplier
• Real-Time Leaderboard — GitHub GraphQL data refreshed on a schedule via the Cache Updater microservice
• Shareable URLs — Every filter combination is encoded in the URL — bookmark or share any leaderboard view
• CSV Export — Download any filtered leaderboard as a CSV file for hiring, analytics, or research
• Hiring Section — Highlights top contributors alongside associated job openings
• Responsive UI — Works across desktop and mobile with Material-UI components
• Cache-First Architecture — Redis-backed distributed cache with async background refresh to minimize API latency
• Multi-Token GitHub Rate Management — Distributes requests across multiple GitHub PATs for resilient throughput
• SEO Build Optimization — Custom Webpack plugins auto-generate sitemap.xml, robots.txt, and favicon.ico

---

Architecture

Major League GitHub is a distributed full-stack application split into two backend microservices and a React frontend:

flowchart TD
    User["User Browser"] --> Frontend["React 19 Frontend"]
    Frontend --> Backend["Backend Service (Port 8450)"]
    Backend --> Redis[("Redis Cache")]
    Backend --> GitHub["GitHub GraphQL API"]
    Backend --> LinkedIn["LinkedIn API (Hiring)"]
    CacheUpdater["Cache Updater (Port 8451)"] --> Redis
    CacheUpdater --> GitHub
    GitHubActions["GitHub Actions CI/CD"] --> Docker["Docker Images"]
    Docker --> GKE["Google Kubernetes Engine"]
    GKE --> Backend
    GKE --> CacheUpdater
    GKE --> Redis

Loading

Backend Request Flow

sequenceDiagram
    participant Client as "Frontend"
    participant Controller as "ContributorController"
    participant Cache as "CacheServiceAbs"
    participant Service as "GithubService"
    participant Rate as "GithubTokenRateManager"
    participant GitHub as "GitHub GraphQL API"

    Client->>Controller: GET /api/contributors/search
    Controller->>Cache: isCacheReady()?
    Cache-->>Controller: true
    Controller->>Cache: getHttpResponse(filters, loader)
    Cache->>Service: getTopContributorsIn(cities, language)
    Service->>Rate: getBestAvailableClient()
    Rate-->>Service: WebClient
    Service->>GitHub: POST /graphql
    GitHub-->>Service: JSON response
    Service-->>Cache: List<Contributor>
    Cache-->>Controller: Cached response
    Controller-->>Client: ApiResponse<List<Contributor>>

Loading

---

Tech Stack

Layer	Technology
Backend	Java 21 + Spring Boot 3.4
Frontend	React 19 + TypeScript + Material-UI
State Management	URL-driven state via useUrlState hook
API Integration	Axios + React Query
Caching	Redis 7 (distributed)
External Data	GitHub GraphQL API
Hiring Data	LinkedIn API (optional)
Build	Webpack + custom SEO + favicon plugins
Deployment	Docker + Kubernetes (GKE)
CI/CD	GitHub Actions

---

Quick Start

Get the full stack running locally in about 5 minutes.

Prerequisites

• Java 21+, Maven 3.9+
• Node.js 18+, npm 9+
• Docker (for Redis)
• A GitHub Personal Access Token with read:user scope

Run It

# 1. Clone the repository
git clone https://github.com/flamingo-stack/major-league-github.git
cd major-league-github

# 2. Start Redis
docker run -d -p 6379:6379 --name mlg-redis redis:7

# 3. Start the Backend Service (port 8450)
cd backend
GITHUB_TOKENS=your_github_pat \
SPRING_REDIS_HOST=localhost \
SPRING_REDIS_PORT=6379 \
mvn spring-boot:run -Pbackend-service

# 4. (New terminal) Start the Cache Updater (port 8451)
cd backend
GITHUB_TOKENS=your_github_pat \
SPRING_REDIS_HOST=localhost \
SPRING_REDIS_PORT=6379 \
mvn spring-boot:run -Pcache-updater

# 5. (New terminal) Start the Frontend Dev Server
cd frontend
npm install
BACKEND_API_URL=http://localhost:8450 npx webpack serve

Open http://localhost:8450 in your browser. The leaderboard will appear once the PreCacheService finishes its first warm-up pass (typically 30–90 seconds).

API Quick Test

curl http://localhost:8450/api/contributors/search?languageId=java&maxResults=5

{
  "status": "success",
  "message": "Found 5 contributors matching the criteria",
  "data": [...]
}

---

Project Structure

major-league-github/
├── backend/                  # Java 21 + Spring Boot 3.4
│   └── src/main/java/cx/flamingo/analysis/
│       ├── controller/       # REST API controllers (port 8450)
│       ├── service/          # Business logic + GitHub integration
│       ├── cache/            # Cache abstraction + Redis/disk implementations
│       ├── config/           # Spring configuration (CORS, Redis, scheduling)
│       ├── graphql/          # GitHub GraphQL query builder
│       ├── model/            # Domain models (Contributor, City, Region, etc.)
│       └── rate/             # GitHub token rate management
├── frontend/                 # React 19 + TypeScript (Webpack)
│   └── src/
│       ├── components/       # UI components (ContributorsTable, FiltersPanel)
│       ├── hooks/            # useUrlState, useNearestRegion
│       ├── services/         # Axios API service layer
│       └── types/            # TypeScript API type definitions
└── docs/                     # Full documentation

---

Contributor Scoring

The scoring formula is transparent and intentional:

Score = commits × max(starsReceived, 1) × recencyMultiplier

Component	Source	Effect
commits	GitHub contributions calendar	Rewards high activity volume
starsReceived	Stars on language-specific repos	Rewards community impact
recencyMultiplier	Activity freshness (1.0–2.0)	Rewards recent contributions

---

REST API

Endpoint	Description
GET /api/contributors/search	Search and rank contributors by filters
GET /api/contributors/export	Download leaderboard as CSV
GET /api/autocomplete/cities	City autocomplete suggestions
GET /api/autocomplete/languages	Language autocomplete suggestions
GET /api/autocomplete/regions	Region autocomplete suggestions
GET /api/autocomplete/states	State autocomplete suggestions
GET /api/autocomplete/teams	MLS team autocomplete suggestions
GET /api/entities/teams/{id}	Look up an MLS team by ID
GET /api/entities/regions/{id}	Look up a region by ID
GET /api/hiring/manager	Hiring manager profile
GET /api/hiring/jobs	Active job openings
GET /actuator/health	Backend health check

---

Documentation

📚 See the Documentation for comprehensive guides including getting started tutorials, local development setup, architecture deep-dives, and security guidelines.

• Introduction — What is Major League GitHub?
• Prerequisites — Required tools and accounts
• Quick Start — Run the full stack in 5 minutes
• First Steps — Explore features after startup
• Local Development — Full development workflow
• Architecture Overview — System design and module map

---

Contributing

Contributions are welcome! Please read CONTRIBUTING.md to understand the development workflow, code style, branching conventions, and PR process.

• 🐛 Report a bug
• 💡 Request a feature
• 🔒 Report a security vulnerability

---

Built with 💛 by the Flamingo team
